Matica XL8300

Matica´s new XL8300 is an innovative retransfer printer, that specializes in
printing exceptionally high quality oversized cards for the event management
industry, and is capable of printing up to 128 full color cards per hour. The
XL8300 offers contactless encoding as an option and like the rest of the XID
Series 8 family it retains high quality print production.

Prints Big Card Badges for Events, even Cards with Sizes 12.9 x 9 Cm

The event management and conferencing market is a growth sector that includes
conventions, trade shows and sports events such as the Olympics, Formula One,
golf, football, tennis and all other competitions. Similarly, corporate environments
may need wide format cards where access control requires immediate personal
identification. At sites of specialized security the XL8300 has the option to encode
contactless cards for electronic access control. Further, the XL8300 can print text,
logo and images in UV ink and prints efficiently on a range of card materials
including PVC, ABS and PET so its flexibility surpasses the market’s alternative
solutions.

Producing non-standard, wide format cards that reflect the calibre of events
and conference organizers’ own branding is a challenge in today’s market, and
it is critical that companies can feel confident that visitor and guest cards show
them in a good light. The XL8300 achieves that, in part because its retransfer
technology is superior.

It´s compact design making it supremely practical and a unique solution to issue
wide badge formats on site. The XL8300 is therefore entering a market with
limited competition and offers a unique solution to issue wide badge format
in color HQ printing based on Matica’s most sought after printer in the desktop
arenas: the XID8300.

As one the newest members to Matica’s XID Series 8 family, the new XL8300 also
benefits from its proven and well-known retransfer technology and offers the
biggest individually printable areas in the market.

Print Method
Dye-sublimation retransfer (YMCK) / Thermal transfer (Monochrome “K”)
Print Mode
Single side retransfer printing on oversized cards
Print Resolution
300 dpi
Print Speed
Up to 128 cards per hour
Printhead
Lifetime warranty (using EDIsecure® materials)
Card Types
PVC, ABS, PET
Card Thickness
0.25 – 1.02 mm (hopper adjustement required)
Input Hopper Capacity
100 cards (0.76 mm)
Output Hopper Capacity
100 cards (0.76 mm)
Interface
USB 2.0 and Ethernet
Operating System Support
Support Windows XP, 7, 8
Power Supply
100/120 V and 220/240 V, 50/60 Hz FCC, CE, UL, GOST-R, and CCC approved
Operating Environment
15°C to 30°C, 35% to 70% noncondensing humidity
Printer Dimensions
549 x 322 x 411 mm (WxDxH) (Incl. oversized card feeder and hopper)
Weight
15,6 kg (excluding optional built-in items)
