ZKTeco F35 Outdoor Access Control Terminal with In-Glass Fingerprint & Video Intercom

Additional information

Product Description

ZKTeco F35 is a standalone outdoor access control terminal that combines in-glass fingerprint, RFID card and PIN verification with a built-in 2MP camera and SIP video intercom, all in an IP65 aluminium-alloy housing. It controls a door on its own, without a separate controller, and doubles as a time attendance terminal when connected to ZKBioTime. Finloyd supplies, installs and supports the F35 across Riyadh, Jeddah and Al Khobar.

Why choose the ZKTeco F35?

In-glass fingerprint, no sensor button: the fingerprint sensor sits under the glass panel, so there is no exposed prism to scratch, collect dust or bake in the sun. Verification takes under 0.3 seconds.
Built for Saudi outdoor entrances: IP65 waterproof and dustproof, IK04 vandal resistance, aluminium alloy frame and an operating range up to 55 °C.
Access control + video intercom in one device: 2.4″ colour screen, 2MP wide-angle camera (145° diagonal), microphone and speaker for one-way video calls to a ZKTeco indoor monitor over SIP.
Three ways to open the door: fingerprint, card or PIN, or combine them for higher-security doors.
Large capacity: 10,000 users, 10,000 fingerprints, 10,000 cards and 500,000 transaction logs.
Access control or attendance: ships with access-control (AC) push firmware that can be switched to time-attendance (TA) push for ZKBioTime payroll and HR reporting.

Who is the F35 for?

The F35 suits any door that needs controlled entry plus a way for visitors to call inside:

Company offices and staff entrances
Warehouses, factories and industrial sites
Villas, residential compounds and apartment buildings
Clinics, hospitals and schools
Retail branches, server rooms and restricted areas
Construction and project sites with outdoor gates

Card technologies supported

The standard F35 reads 125 kHz EM/ID cards. For other card types, Finloyd supplies the unit with an optional multi-tech module:

Module	Cards supported (125 kHz + 13.56 MHz)
Standard	ID (EM) 125 kHz
Module 1	ID, IC (MIFARE), DESFire EV1/EV2
Module 2	Module 1 + FeliCa, Legic, HID Prox
Module 3	Module 2 + HID iClass
Module 4	ID, IC, DESFire Encrypted

Already using cards in your building? Tell us the card type and we will match the right module. Finloyd also prints and encodes proximity and RFID cards in-house.

A complete door access system

The F35 connects directly to an electric lock, door sensor, exit button, alarm and doorbell. It offers TCP/IP, optional 2.4 GHz Wi-Fi, Wiegand in/out and RS485 for an external reader, so you can add an exit reader on the inside of the door. Manage it from ZKBio CVAccess or ZKBioTime software on Windows, through the built-in web server, or from the ZSmart mobile app. ONVIF support lets the camera feed into compatible NVRs.

ZKTeco F35 specifications

Model	ZKTeco F35 (F Series)
Verification	Fingerprint / Card / Password (touch keypad)
Fingerprint sensor	In-glass fingerprint (Z-ID), ZKFingerprint V10.0
Verification speed	< 0.3 sec
FAR / FRR	≤ 0.0001% / ≤ 0.01%
User / fingerprint / card capacity	10,000 / 10,000 / 10,000 (1:N)
Transaction logs	500,000
Display	2.4″ TFT colour LCD
Camera	2MP, FOV 145° diagonal / 118° horizontal / 62° vertical
Audio	Built-in microphone and 1 W speaker
Video intercom	One-way video to ZKTeco indoor monitor via SIP (SIP client optional)
Card reader	125 kHz ID standard; multi-tech modules optional
Communication	TCP/IP, Wi-Fi 2.4 GHz (optional), Wiegand in/out, RS485
Door I/O	Electric lock, door sensor, exit button, alarm, doorbell, aux in/out
Key functions	Web server, ADMS, anti-passback, access levels, groups, holidays, event photo capture, tamper alarm, ONVIF, AC/TA push, HTTPS/SSH
Software	ZKBio CVAccess, ZKBioTime; ZSmart mobile app
CPU / memory	1.2 GHz dual core; 256 MB RAM, 512 MB ROM; Linux
Protection	IP65 waterproof & dustproof, IK04 vandal resistant
Housing	Aluminium alloy
Power	12 V DC, 3 A
Operating temperature	-5 °C to 55 °C
Humidity	10%–90% RH, non-condensing
Dimensions	195 × 75 × 25.35 mm
Net weight	0.52 kg
Installation	Wall mount (single gang box compatible)
Certifications	CE, FCC, RoHS, ISO 9001, ISO 14001

Why buy the ZKTeco F35 from Finloyd?

Since 2008 in Saudi Arabia: a leading supplier of access control and time attendance devices in the Kingdom.
Supply, installation and setup: our technicians wire the lock, configure users and connect the F35 to your network and software.
Local support in Riyadh, Jeddah and Al Khobar: warranty service and spare parts from Saudi teams.
One supplier for the whole door: electric locks, exit buttons, RFID cards and card printers from the same company.

Request a quote for the ZKTeco F35, or call Finloyd to plan a full access control project for your site.

Frequently asked questions

What is the ZKTeco F35?

The ZKTeco F35 is a standalone outdoor access control terminal with in-glass fingerprint, RFID card and PIN verification, a 2MP camera and SIP video intercom, protected to IP65.

Can the ZKTeco F35 be installed outdoors in Saudi Arabia?

Yes. It is IP65 rated against water and dust, has an aluminium alloy body and operates from -5 °C to 55 °C. For gates in direct afternoon sun, Finloyd recommends a small canopy to keep the screen readable and the unit within its temperature range.

Does the F35 support face recognition?

No. The F35 verifies by fingerprint, card and PIN; its camera is used for video intercom and event photos. For face or palm recognition, ask Finloyd about ZKTeco SpeedFace terminals.

Can the F35 be used for time attendance?

Yes. Its firmware can switch from access-control push to time-attendance push, so it works with ZKBioTime for attendance reports and payroll exports.

Which cards does the ZKTeco F35 read?

125 kHz EM/ID cards as standard. Optional modules add MIFARE (IC), DESFire EV1/EV2, FeliCa, Legic, HID Prox and HID iClass.

How does the F35 video intercom work?

A visitor presses the call button and the F35 sends one-way video and two-way audio to a compatible ZKTeco indoor monitor over SIP, where the door can be released.

How many users can the F35 store?

10,000 users, 10,000 fingerprints, 10,000 cards and 500,000 transaction records.

Does Finloyd install the ZKTeco F35?

Yes. Finloyd supplies, installs and configures the F35 in Riyadh, Jeddah and Al Khobar, including the electric lock, exit button, cards and software setup.
